Multi-lane Checkweigher SCP6

SCP6 is a dynamic checkweighing system for small packages. it supports multi-lane control, fast data export and GMP compliance.

Categories	Checkweigher
Brand	SamaGarm
Model	SCP6
Weighing Range	0.1-100g
Collect conveying width	200mm
Weighing speed	40-50 cuts/minute
Weighting accuracy	±0.02-0.05g
Number of columns	1-20 Lanes Customized
Operation screen	Customized
Download
Update Time	Aug 4,2025

Contact Now

Detail Information

Multi-lane Checkweigher SCP6

Introduction

The SCP6 is a multi-lane dynamic checkweighing system for precision weighing of small packages like tablets and stickpacks. Designed as a flexible checkweigher machine, it supports 1 to 20 lanes and complies with GMP standards. With one-click data export and traceability of up to 300,000 records, it’s ideal for regulated industries. The system features intuitive multi-language controls, quick dismantling, and easy cleaning. An advanced overload protection device safeguards sensors from damage under extreme pressure. SCP delivers unmatched performance in small package checkweighers, making it a trusted checkweighing scale for high-speed, high-accuracy production lines.

Multi-lane Checkweigher SCP6

Features

Multi-Lane Checkweighing Flexibility

Supports 1 to 20 lanes for precise checkweighing of small packages.

Ideal as a tablet checkweigher or stickpack checkweigher.

Superior Precision and Stability

Advanced sensors ensure high accuracy even at high-speed weighing.

Maintains consistent parcel weigh results across lanes.

GMP-Compliant Design

Meets stringent pharmaceutical and food industry standards.

Perfect for clean and controlled production environments.

Customizable Checkweigher Up to 20 Lanes

Customizable Up to 20 Lanes

Flexible configuration supports from 1 to 20 lanes, adapting perfectly to your production capacity and inspection needs.

Compact and Modular Construction

Space-saving design fits seamlessly into existing lines.

Flexible lane configuration adapts to changing production needs.

Massive Data Storage and Traceability

Stores up to 300,000 records for full production traceability.

Simplifies compliance reporting with one-click data export.

Multi-lane Checkweigher SCP6

Technical Parameters

Product model	SCP6
Collect conveying width	200mm
Weighting accuracy	±0.02-0.05g
Length of conveyor belt	Customized
Product output table height	270-750mm

Weighing Range	0.1-100g
weighing speed	40-50 cuts/minute
number of columns	1-20 Lanes Customized
Operation screen	Customized

* The maximum checkweighing speed and accuracy may vary depending on the actual product being tested and the installation environment.
* When selecting the model, pay attention to the direction of product movement on the conveyor belt. For transparent or semi-transparent products, please contact our company.

File Downloads

For more product related parameter files, please contact us.

SameGram Product Brochure（18.62 MB）

Multi-lane Checkweigher Applications

Pharmaceutical Industry

It is suitable for weight detection and missing tablet/missing pack screening of products such as capsules, tablets, and stick-packs, and complies with GMP and CFR 21 Part 11 requirements.
